Outpost™ Hybrid Power Suite – Light (OHPS-L)

Modular, Scalable Hybrid Power for Ground, Tactical & Utility Vehicle Power

– Rapidly Deployable  |  Turnkey AC & DC Hybrid Power
– Industry-best Form Factors  |  Matching Form Factors Across Components
– Quiet, Energy-efficient, Low Signature  |  Clean Power for Sensitive Electronics
– Easily Integrated on a Vehicle or Trailer  |  Remote Monitoring & Control
– Portable Components Interchange to form both Ground Power & Onboard Vehicle / APU Solutions
– Generators use military fuels (JP5-8 / F34) and most other common diesel fuels
– Parallel Synchronization for Scalable Plug & Play Power up to 10kW for Most Practical Scenarios  |  Potential to Scale to 30kW

OHPS-L solutions consist of four building block components in two standard form factors:

  • Outpost™ Hybrid Generator (OHG)
  • Outpost™ Energy Router (OER)
  • Outpost™ Energy Storage (OES), Endurance™ Compact
  • EndurancePortable Solar Panels or Expedition™ Portable Solar Arrays
2kW / 28V DC
Hybrid Diesel Generator

Power Output
: 2kW

Connections (In)
: NATO STANAG 4074 (24-28V DC jump start) | 24V DC trickle charge, | External 5V Auto Start/Stop & CANBUS port | RJ45 port

Connections (Out)
: NATO STANAG 4074 (28V DC) | MIL-DTL-38999 18-pin (28V DC) | USB 5V DC | RJ45 port

Remote Comms/Operation
: Modbus TCP via Ruggedized RJ45 port | CANBUS Master Remote Panel | External 5V Auto Start/Stop

Dimensions/Weight
:
18.5″ x 14.6″ x 17.7″ / 121.3 lbs.
2kVA / 120V AC*
Hybrid Diesel Generator

Power Output
: 2kVA

Connections (In)
: 24V DC trickle charge | External 5V Auto Start/Stop & CANBUS port | RJ45 port

Connections (Out)
: 120V/60Hz (20A) AC* | AC Synchronization | USB 5V DC | RJ45 port

Remote Comms/Operation
: Modbus TCP via Ruggedized RJ45 port | CANBUS Master Remote Panel | External 5V Auto Start/Stop

Dimensions/Weight
:
18.5″ x 14.6″ x 17.7″ / 132.3 lbs.

*3kVA 230V/50Hz option available

OHG 4000™

4kW / 28V DC
Hybrid Diesel Generator

Power Output
: 4kW

Connections (In)
: NATO STANAG 4074 (28V DC jump start) | 24V trickle charge | External 5V Auto Start/Stop & CANBUS port | RJ45 port

Connections (Out)
: NATO STANAG 4074 (28V DC) | MIL-DTL-38999 18-pin (28V DC) | USB 5V DC | RJ45 port

Remote Comms/Operation
: Modbus TCP via Ruggedized RJ45 port | CANBUS Master Remote Panel | External 5V Auto Start/Stop

Dimensions/Weight
:
22.4″ x 19.7″ x 21.7″ / 198.4 lbs.

OHG 5000™

5kVA / 120V AC*
Hybrid Diesel Generator

Output
: 5kVA

Connections (In)
: 24V trickle charge | External 5V Auto Start/Stop & CANBUS Port | RJ45 Port

Connections (Out)
: (2) 120V/60Hz AC | USB 5V DC | RJ45 Port

Remote Comms/Operation
: Modbus TCP via Ruggedized RJ45 port | CANBUS Master Remote Panel | External 5V Auto Start/Stop

Dimensions/Weight
:
22.4″ x 19.7″ x 21.7″ / 220.5 lbs.

*230V/50Hz option available

OER 3000™

3kW Hybrid Controller & Power Manager

Connections (In)
: (2) NATO STANAG 4074 (28V DC / 80A) | (2) 120V/60Hz* (30A)

Connections (Out)
: (2) NATO STANAG 4074 (28V DC / 80A) | (2) 120V/60Hz* (30A)

Energy Storage
: 2.7kWh Integrated Li6T battery

Dimensions
: 18.5″ x 14.6″ x 17.7″

*230V/50Hz option available

OER 5000™

5kW Hybrid Controller & Power Manager

Connections (In)
: (2) NATO STANAG 4074 (28V DC / 80A) | (2) 110V/60Hz* (50A)

Connections (Out)
: (2) NATO STANAG 4074 (28V DC / 80A) | (2) 110V/60Hz* (50A)

Energy Storage
: External (use with OES 5000™ or other 24V battery)

Dimensions
: 18.5″ x 14.6″ x 17.7″

*230V/50Hz option available

OES 5000™

5.4kWh Energy Storage Module

Batteries
: (2) Integrated 2.7kWh Li6T

Connections (In)
: (1) NATO STANAG 4074 (28V DC / 150A)

Connections (Out)
: (1) NATO STANAG 4074 (28V DC / 150A)

Dimensions
: 18.5″ x 14.6″ x 17.7″

Modular and Scalable Power from 2 to 10kW
